[SM6225][Android13]user版本默认允许root和remount

慈云数据 2024-04-11 技术支持 111 0

开发平台基本信息

芯片: 高通SM6225
版本: Android 13
kernel: msm-5.15

[SM6225][Android13]user版本默认允许root和remount
（图片来源网络，侵删）

问题描述

       刚刚从Framework踏入性能的小殿堂，User版本默认是不会开启root权限的，而且一般调试需要设置一下CPU GPU DDR performance模式或者修改一些schedule util等调核调频节点去对比复测，userdebug版本的话本身整机性能就比user卡很多，有时候使用userdebug去复测会对测试结果有较大影响，与user测试结果存在很大差距。

      基于以上，user+root闪亮登场，性能与user一致，而且还有root和remount权限，可以自主执行修改节点或者push等操作。话不多说，让我们进入整体，看看如何实现user+root+remount.

[SM6225][Android13]user版本默认允许root和remount
（图片来源网络，侵删）

基线代码判断逻辑：

1.adb代码会检测相关属性

ro.secure

ro.debuggable (通过调用__android_log_is_debuggable()获取返回值)

2.代码path

2.1 adbd启动时检查属性，决定是否进行权限降级到AID_SHELL

path：system/adb/core/daemon/main.cpp line:121

if (should_drop_privileges()){

… …

2.2 system/adb/core/下搜索__android_log_is_debuggable()

3.修改思路

3.1 should_drop_privileges() 修改强制返回false，保持adb root用户级别

3.2 __android_log_is_debuggable() 返回true



packages/modules/adb/daemon/main.cpp
static bool should_drop_privileges() {
    // The properties that affect `adb root` and `adb unroot` are ro.secure and
    // ro.debuggable. In this context the names don't make the expected behavior
    // particularly obvious.
    //
    // ro.debuggable:
    //   Allowed to become root, but not necessarily the default. Set to 1 on
    //   eng and userdebug builds.
    //
    // ro.secure:
    //   Drop privileges by default. Set to 1 on userdebug and user builds.
    bool ro_secure = android::base::GetBoolProperty("ro.secure", true);
    bool ro_debuggable = __android_log_is_debuggable();

    // Drop privileges if ro.secure is set...
    bool drop = ro_secure;

    std::string build_prop = android::base::GetProperty("ro.build.type", "");
    bool adb_build_root = (build_prop == "userdebug");
    if (adb_build_root) {
	    return false;
    }

    // ... except "adb root" lets you keep privileges in a debuggable build.
    std::string prop = android::base::GetProperty("service.adb.root", "");
    bool adb_root = (prop == "1");
    bool adb_unroot = (prop == "0");
    if (ro_debuggable && adb_root) {
        drop = false;
    }
    // ... and "adb unroot" lets you explicitly drop privileges.
    if (adb_unroot) {
        drop = true;
    }

    return drop;
}

解决方案：

1.注释掉DropCapabilitiesBoundingSet

说明：这个文件负责创建应用程序进程，并设置它们的权限和能力。需要注释掉DropCapabilitiesBoundingSet函数中的代码，以防止它删除adbd进程的任何能力。

文件路径：qssi/frameworks/base/core/jni/com_android_internal_os_Zygote.cpp

详细修改：

--- a/core/jni/com_android_internal_os_Zygote.cpp
+++ b/core/jni/com_android_internal_os_Zygote.cpp
@@ -681,7 +681,7 @@
 }

 static void DropCapabilitiesBoundingSet(fail_fn_t fail_fn) {
-  for (int i = 0; prctl(PR_CAPBSET_READ, i, 0, 0, 0) >= 0; i++) {;
+  /*for (int i = 0; prctl(PR_CAPBSET_READ, i, 0, 0, 0) >= 0; i++) {;
     if (prctl(PR_CAPBSET_DROP, i, 0, 0, 0) == -1) {
       if (errno == EINVAL) {
         ALOGE("prctl(PR_CAPBSET_DROP) failed with EINVAL. Please verify "
@@ -690,7 +690,7 @@
         fail_fn(CREATE_ERROR("prctl(PR_CAPBSET_DROP, %d) failed: %s", i, strerror(errno)));
       }
     }
-  }
+  }*/
 }

 static void SetInheritable(uint64_t inheritable, fail_fn_t fail_fn) {

2.启用abdb root模式添加remount，保持adb root用户级别

2.1 启用adbd进程的root模式，并添加remount到required中

说明：这个文件定义了adbd模块的编译选项和依赖项。需要添加-DALLOW_ADBD_ROOT=1到cflags中，以启用adbd进程的root模式，并添加remount到required中，以允许adbd进程重新挂载系统分区。

文件路径：qssi/packages/modules/adb/Android.bp

详细修改：

--- a/Android.bp
+++ b/Android.bp
@@ -50,6 +50,7 @@
         "-Wvla",
         "-DADB_HOST=1",         // overridden by adbd_defaults
         "-DANDROID_BASE_UNIQUE_FD_DISABLE_IMPLICIT_CONVERSION=1",
+        "-DALLOW_ADBD_ROOT=1",
     ],
     cpp_std: "experimental",

@@ -112,7 +113,14 @@
     name: "adbd_defaults",
     defaults: ["adb_defaults"],

-    cflags: ["-UADB_HOST", "-DADB_HOST=0"],
+    cflags: [
+        "-UADB_HOST",
+        "-DADB_HOST=0",
+        "-UALLOW_ADBD_ROOT",
+        "-DALLOW_ADBD_ROOT=1",
+        "-DALLOW_ADBD_DISABLE_VERITY",
+        "-DALLOW_ADBD_NO_AUTH",
+    ],
 }
cc_defaults {
    name: "host_adbd_supported",
    host_supported: true,
    target: {
        linux: {
            enabled: true,
            host_ldlibs: [

@@ -606,6 +614,8 @@
        "libcrypto_utils",
        "libcutils_sockets",
        // APEX dependencies.
        "libadbd_auth",
        "libadbd_fs",
        "libcrypto",
        "liblog",
    ],

+    required: ["remount",],
    target: {
        android: {
            srcs: [
                "daemon/abb_service.cpp",
                "daemon/framebuffer_service.cpp",
                "daemon/mdns.cpp",
                "daemon/restart_service.cpp",
            ],
            shared_libs: [
                "libmdnssd",
2.2 保持adb root用户级别

说明：这个文件是adbd进程的主要入口点。我们需要修改should_drop_privileges函数，让它总是返回false，以防止它降低adbd进程的权限。should_drop_privileges() 修改强制返回false，保持adb root用户级别

文件路径：qssi/packages/modules/adb/daemon/main.cpp

详细修改：

--- a/daemon/main.cpp
+++ b/daemon/main.cpp
@@ -74,6 +74,7 @@
     //
     // ro.secure:
     //   Drop privileges by default. Set to 1 on userdebug and user builds.
+    return false;
     bool ro_secure = android::base::GetBoolProperty("ro.secure", true);
     bool ro_debuggable = __android_log_is_debuggable();

3.允许adbd进程关闭Verity检查,关闭selinux

3.1 允许adbd进程关闭Verity检查

说明：这个文件定义了fs_mgr模块的编译选项和依赖项。fs_mgr模块负责管理设备上的文件系统。我们需要修改-DALLOW_ADBD_DISABLE_VERITY=0为-DALLOW_ADBD_DISABLE_VERITY=1，以允许adbd进程关闭Verity检查。

文件路径：qssi/system/core/fs_mgr/Android.bp

详细修改：

--- a/fs_mgr/Android.bp
+++ b/fs_mgr/Android.bp
@@ -109,7 +109,8 @@
         "libfstab",
     ],
     cppflags: [
-        "-DALLOW_ADBD_DISABLE_VERITY=0",
+        "-UALLOW_ADBD_DISABLE_VERITY",
+        "-DALLOW_ADBD_DISABLE_VERITY=1",
     ],
     product_variables: {
         debuggable: {
@@ -237,7 +238,8 @@
         "fs_mgr_remount.cpp",
     ],
     cppflags: [
-        "-DALLOW_ADBD_DISABLE_VERITY=0",
+        "-UALLOW_ADBD_DISABLE_VERITY",
+        "-DALLOW_ADBD_DISABLE_VERITY=1",
     ],
     product_variables: {
         debuggable: {
3.2 允许init进程编译方式

说明：这个文件定义了init模块的编译选项和依赖项。init模块是设备启动时运行的第一个进程，负责初始化系统服务和属性。

-DALLOW_FIRST_STAGE_CONSOLE=1：允许init进程在第一阶段打开控制台输出

-DALLOW_LOCAL_PROP_OVERRIDE=1：允许init进程覆盖本地属性

-DALLOW_PERMISSIVE_SELINUX=1：允许init进程设置SELinux为permissive模式

-DREBOOT_BOOTLOADER_ON_PANIC=1：允许init进程在发生内核崩溃时重启到bootloader模式

-DWORLD_WRITABLE_KMSG=1：允许init进程设置kmsg文件为可写

-DDUMP_ON_UMOUNT_FAILURE=1：允许init进程在卸载分区失败时生成内存转储

-DSHUTDOWN_ZERO_TIMEOUT=1：允许init进程在收到关机命令时立即执行

文件路径：qssi/system/core/init/Android.bp

详细修改：

--- a/init/Android.bp
+++ b/init/Android.bp
@@ -136,13 +136,20 @@
         "-Wno-unused-parameter",
         "-Werror",
         "-Wthread-safety",
-        "-DALLOW_FIRST_STAGE_CONSOLE=0",
-        "-DALLOW_LOCAL_PROP_OVERRIDE=0",
-        "-DALLOW_PERMISSIVE_SELINUX=0",
-        "-DREBOOT_BOOTLOADER_ON_PANIC=0",
-        "-DWORLD_WRITABLE_KMSG=0",
-        "-DDUMP_ON_UMOUNT_FAILURE=0",
-        "-DSHUTDOWN_ZERO_TIMEOUT=0",
+        "-UALLOW_FIRST_STAGE_CONSOLE",
+        "-DALLOW_FIRST_STAGE_CONSOLE=1",
+        "-UALLOW_LOCAL_PROP_OVERRIDE",
+        "-DALLOW_LOCAL_PROP_OVERRIDE=1",
+        "-UALLOW_PERMISSIVE_SELINUX",
+        "-DALLOW_PERMISSIVE_SELINUX=1",
+        "-UREBOOT_BOOTLOADER_ON_PANIC",
+        "-DREBOOT_BOOTLOADER_ON_PANIC=1",
+        "-UWORLD_WRITABLE_KMSG",
+        "-DWORLD_WRITABLE_KMSG=1",
+        "-UDUMP_ON_UMOUNT_FAILURE",
+        "-DDUMP_ON_UMOUNT_FAILURE=1",
+        "-USHUTDOWN_ZERO_TIMEOUT",
+        "-DSHUTDOWN_ZERO_TIMEOUT=1",
         "-DINIT_FULL_SOURCES",
         "-DINSTALL_DEBUG_POLICY_TO_SYSTEM_EXT=0",
     ],
@@ -394,13 +401,20 @@
         "-Wextra",
         "-Wno-unused-parameter",
         "-Werror",
-        "-DALLOW_FIRST_STAGE_CONSOLE=0",
-        "-DALLOW_LOCAL_PROP_OVERRIDE=0",
-        "-DALLOW_PERMISSIVE_SELINUX=0",
-        "-DREBOOT_BOOTLOADER_ON_PANIC=0",
-        "-DWORLD_WRITABLE_KMSG=0",
-        "-DDUMP_ON_UMOUNT_FAILURE=0",
-        "-DSHUTDOWN_ZERO_TIMEOUT=0",
+        "-UALLOW_FIRST_STAGE_CONSOLE",
+        "-DALLOW_FIRST_STAGE_CONSOLE=1",
+        "-UALLOW_LOCAL_PROP_OVERRIDE",
+        "-DALLOW_LOCAL_PROP_OVERRIDE=1",
+        "-UALLOW_PERMISSIVE_SELINUX",
+        "-DALLOW_PERMISSIVE_SELINUX=1",
+        "-UREBOOT_BOOTLOADER_ON_PANIC",
+        "-DREBOOT_BOOTLOADER_ON_PANIC=1",
+        "-UWORLD_WRITABLE_KMSG",
+        "-DWORLD_WRITABLE_KMSG=1",
+        "-UDUMP_ON_UMOUNT_FAILURE",
+        "-DDUMP_ON_UMOUNT_FAILURE=1",
+        "-USHUTDOWN_ZERO_TIMEOUT",
+        "-DSHUTDOWN_ZERO_TIMEOUT=1",
         "-DLOG_UEVENTS=0",
         "-DSEPOLICY_VERSION=30", // TODO(jiyong): externalize the version number
     ],
3.3 关闭selinux 将enforce置为Permissive

说明：这个文件实现了一些与SELinux相关的函数。我们需要修改IsEnforcing函数，让它总是返回false，以防止它检查系统属性或内核参数是否设置了SELinux的强制执行。

文件路径：qssi/system/core/init/selinux.cpp

详细修改：

--- a/init/selinux.cpp
+++ b/init/selinux.cpp
@@ -123,6 +123,7 @@
 }

 bool IsEnforcing() {
+    return false;
     // close selinux for user version with root
     #if defined(LCT_BUILD_TYPE_FACTORY)
     return false;

4.user 版本不允许 permissive domains

说明：user 版本启用 overlayfs 来装载 remount 对应分区 user 版本不允许 permissive domains

文件路径：system/sepolicy/Android.mk

详细修改：

--- a/Android.mk
+++ b/Android.mk
@@ -613,7 +613,7 @@
 ifneq ($(filter address,$(SANITIZE_TARGET)),)
   local_fc_files += $(wildcard $(addsuffix /file_contexts_asan, $(PLAT_PRIVATE_POLICY)))
 endif
-ifneq (,$(filter userdebug eng,$(TARGET_BUILD_VARIANT)))
+ifneq (,$(filter user userdebug eng,$(TARGET_BUILD_VARIANT)))
   local_fc_files += $(wildcard $(addsuffix /file_contexts_overlayfs, $(PLAT_PRIVATE_POLICY)))
 endif

5.打开 USB 调试时默认授权，默认user版本编译remount。

5.1 默认开启usb调试

说明：默认开启usb调试。

文件路径：build/make//core/main.mk

详细修改：

--- a/core/main.mk
+++ b/core/main.mk
@@ -365,11 +365,11 @@
 tags_to_install :=
 ifneq (,$(user_variant))
   # Target is secure in user builds.
-  ADDITIONAL_SYSTEM_PROPERTIES += ro.secure=1
+  ADDITIONAL_SYSTEM_PROPERTIES += ro.secure=0
   ADDITIONAL_SYSTEM_PROPERTIES += security.perf_harden=1

   ifeq ($(user_variant),user)
-    ADDITIONAL_SYSTEM_PROPERTIES += ro.adb.secure=1
+    ADDITIONAL_SYSTEM_PROPERTIES += ro.adb.secure=0
   endif

   ifeq ($(user_variant),userdebug)
@@ -377,7 +377,7 @@
     tags_to_install += debug
   else
     # Disable debugging in plain user builds.
-    enable_target_debugging :=
+    enable_target_debugging := true
   endif

   # Disallow mock locations by default for user builds
@@ -399,7 +399,7 @@
   ADDITIONAL_SYSTEM_PROPERTIES += dalvik.vm.lockprof.threshold=500
 else # !enable_target_debugging
   # Target is less debuggable and adbd is off by default
-  ADDITIONAL_SYSTEM_PROPERTIES += ro.debuggable=0
+  ADDITIONAL_SYSTEM_PROPERTIES += ro.debuggable=1
 endif # !enable_target_debugging

 ## eng ##
5.2 添加remount

说明：user版本默认不会编译remount,即system/bin/remount不存在，需要将remount添加到默认编译列表里面。

文件路径：build/make/target/product/base_system.mk

详细修改：

--- a/target/product/base_system.mk
+++ b/target/product/base_system.mk
@@ -287,6 +287,7 @@
     wificond \
     wifi.rc \
     wm \
+    remount \

 ifneq ($(TARGET_HAS_LOW_RAM), true)
 PRODUCT_PACKAGES += \
@@ -388,7 +389,6 @@
     procrank \
     profcollectd \
     profcollectctl \
-    remount \
     servicedispatcher \
     showmap \
     sqlite3 \

总结

通过以上的修改，我们可以在Android 13上实现root功能。

希望这篇博客能对你有所帮助，如果你有任何问题或建议，欢迎留言讨论。谢谢！
