LangChain Agent 执行过程解析

• 什么是LangChain Agent
• 例子
• 工作原理

  什么是LangChain Agent

  简单来说，用户像LangChain输入的内容未知。此时可以有一套工具集合(也可以自定义工具)，将这套自定义工具托管给LLM,让其自己决定使用工具中的某一个(如果存在的话)


  （图片来源网络，侵删）

  例子

  首先，这里自定义了两个简单的工具

  from langchain.tools import BaseTool
  # 天气查询工具 ，无论查询什么都返回Sunny
  class WeatherTool(BaseTool):
      name = "Weather"
      description = "useful for When you want to know about the weather"
      def _run(self, query: str) -> str:
          return "Sunny^_^"
      async def _arun(self, query: str) -> str:
          """Use the tool asynchronously."""
          raise NotImplementedError("BingSearchRun does not support async")
  # 计算工具，暂且写死返回3
  class CustomCalculatorTool(BaseTool):
      name = "Calculator"
      description = "useful for when you need to answer questions about math."
      def _run(self, query: str) -> str:
          return "3"
      async def _arun(self, query: str) -> str:
          raise NotImplementedError("BingSearchRun does not support async")


  接下来是针对于工具的简单调用：注意，这里使用OpenAI temperature=0需要限定为0


  （图片来源网络，侵删）

  from langchain.agents import initialize_agent
  from langchain.llms import OpenAI
  from CustomTools import WeatherTool
  from CustomTools import CustomCalculatorTool
  llm = OpenAI(temperature=0)
  tools = [WeatherTool(), CustomCalculatorTool()]
  agent = initialize_agent(tools, llm, agent="zero-shot-react-description", verbose=True)
  agent.run("Query the weather of this week,And How old will I be in ten years? This year I am 28")


  看一下完整的响应过程：

  I need to use two different tools to answer this question
  Action: Weather
  Action Input: This week
  Observation: Sunny^_^
  Thought: I need to use a calculator to answer the second part of the question
  Action: Calculator
  Action Input: 28 + 10
  Observation: 3
  Thought: I now know the final answer
  Final Answer: This week will be sunny and in ten years I will be 38.


  可以看到LangChain Agent 详细分析了每一个步骤，并且正确的调用了每一个可用的方法，拿到了相应的返回值，甚至在最后还修复了28+10=3这个错误。

  下面看看LangChain Agent是如何做到这点的

  工作原理

  首先看看我输入的问题是什么：

  Query the weather of this week,And How old will I be in ten years? This year I am 28

  查询本周天气，以及十年后我多少岁，今年我28

  LangChain Agent中，有一套模板可以套用：

  PREFIX = """Answer the following questions as best you can. You have access to the following tools:"""
  FORMAT_INSTRUCTIONS = """Use the following format:
  Question: the input question you must answer
  Thought: you should always think about what to do
  Action: the action to take, should be one of [{tool_names}]
  Action Input: the input to the action
  Observation: the result of the action
  ... (this Thought/Action/Action Input/Observation can repeat N times)
  Thought: I now know the final answer
  Final Answer: the final answer to the original input question"""
  SUFFIX = """Begin!
  Question: {input}
  Thought:{agent_scratchpad}"""


  通过这个模板，加上我们的问题以及自定义的工具，会变成下面这个样子,并且附带解释：

  Answer the following questions as best you can.  You have access to the following tools: #  尽可能的去回答以下问题，你可以使用以下的工具：
  Calculator: Useful for when you need to answer questions about math.
   # 计算器：当你需要回答数学计算的时候可以用到
  Weather: useful for When you want to know about the weather #  天气：当你想知道天气相关的问题时可以用到
  Use the following format: # 请使用以下格式(回答)
  Question: the input question you must answer #  你必须回答输入的问题
  Thought: you should always think about what to do
   # 你应该一直保持思考，思考要怎么解决问题
  Action: the action to take, should be one of [Calculator, Weather] #  你应该采取[计算器,天气]之一
  Action Input: the input to the action #  动作的输入
  Observation: the result of the action # 动作的结果
  ...  (this Thought/Action/Action Input/Observation can repeat N times) # 思考-行动-输入-输出 的循环可以重复N次
  T
  hought: I now know the final answer # 最后，你应该知道最终结果了
  Final Answer: the final answer to the original input question # 针对于原始问题，输出最终结果
  Begin! # 开始
  Question: Query the weather of this week,And How old will I be in ten years?  This year I am 28 #  问输入的问题
  Thought:


  通过这个模板向openai规定了一系列的规范，包括目前现有哪些工具集，你需要思考回答什么问题，你需要用到哪些工具，你对工具需要输入什么内容,等等。

  如果仅仅是这样，openAI会完全补完你的回答，中间无法插入任何内容。因此LangChain使用OpenAI的stop参数，截断了AI当前对话。"stop": ["\\nObservation: ", "\\n\\tObservation: "]

  做了以上设定以后，OpenAI仅仅会给到Action和 Action Input两个内容就被stop早停了。

  以下是OpenAI的响应内容：

  I need to use the weather tool to answer the first part of the question, and the calculator to answer the second part.
  Action: Weather
  Action Input: This week


  到这里是OpenAI的响应结果，可见，很简单就拿到了Action和Action Input。

  这里从Tools中找到name=Weather的工具，然后再将This Week传入方法。具体业务处理看详细情况。这里仅返回Sunny。

  由于当前找到了Action和Action Input。 代表OpenAI认定当前任务链并没有结束。因此像请求体后拼接结果：Observation: Sunny 并且让他再次思考Thought:

  开启第二轮思考：

  下面是再次请求的完整请求体:

  Answer the following questions as best you can. You have access to the following tools:
  Calculator: Useful for when you need to answer questions about math.
  Weather: useful for When you want to know about the weather
  Use the following format:
  Question: the input question you must answer
  Thought: you should always think about what to do
  Action: the action to take, should be one of [Calculator, Weather]
  Action Input: the input to the action
  Observation: the result of the action
  ... (this Thought/Action/Action Input/Observation can repeat N times)
  Thought: I now know the final answer
  Final Answer: the final answer to the original input question
  Begin!
  Question: Query the weather of this week,And How old will I be in ten years? This year I am 28
  Thought: I need to use the weather tool to answer the first part of the question, and the calculator to answer the second part.
  Action: Weather
  Action Input: This week
  Observation: Sunny^_^
  Thought:


  同第一轮一样，OpenAI再次进行思考，并且返回Action 和 Action Input 后，再次被早停。

  I need to calculate my age in ten years
  Action: Calculator
  Action Input: 28 + 10


  由于计算器工具只会返回3，结果会拼接出一个错误的结果，构造成了一个新的请求体

  进行第三轮请求：

  Answer the following questions as best you can. You have access to the following tools:
  Calculator: Useful for when you need to answer questions about math.
  Weather: useful for When you want to know about the weather
  Use the following format:
  Question: the input question you must answer
  Thought: you should always think about what to do
  Action: the action to take, should be one of [Calculator, Weather]
  Action Input: the input to the action
  Observation: the result of the action
  ... (this Thought/Action/Action Input/Observation can repeat N times)
  Thought: I now know the final answer
  Final Answer: the final answer to the original input question
  Begin!
  Question: Query the weather of this week,And How old will I be in ten years? This year I am 28
  Thought: I need to use the weather tool to answer the first part of the question, and the calculator to answer the second part.
  Action: Weather
  Action Input: This week
  Observation: Sunny^_^
  Thought:I need to calculate my age in ten years
  Action: Calculator
  Action Input: 28 + 10
  Observation: 3
  Thought:


  此时两个问题全都拿到了结果，根据开头的限定，OpenAi在完全拿到结果以后会返回I now know the final answer。并且根据完整上下文。把多个结果进行归纳总结：下面是完整的相应结果：

  I now know the final answer
  Final Answer: I will be 38 in ten years and the weather this week is sunny.


  可以看到。ai严格的按照设定返回想要的内容，并且还以外的把28+10=3这个数学错误给改正了

  以上，就是LangChain Agent的完整工作流程
